Easy to install pump head, stable flow rate. Lower power, silent working. High definition OLED display screen. Convenient to adjust the speed through digital knob. Power-down memory function.
Technical Parameter
Flow rate range 0.08-930mL/min Speed range 0.1-350rpm, reversible Speed resolution 0.1rpm Speed control Digital knob Control method Mechanical keypad Keypad lifetime 300.000 times Display OLED display(0.96") Communication interface RS485 support MODBUS protocol External control Start/stop direction control (switch signal),0-5V,4-20mA (standard); 0-10V (optional) Power supply DC 24V/1A with power adapter Dimension 180x115x125mm(LxWxH) Weight 800g Condition temperature 0-40°C Relative humidity <80% IP rate IP31 Pump Head Parameter
Model Speed range Tubing Flow rate (mL/min) LabT-UD15 0.1-350rpm 16#，17#，25# 0.08-930
